Westport 130

• Cruising Speed: 13 kn
• Maximum Speed: 24 kn
• Beam: 26' 3"
• Hull Material: GRP
• Max Draft: 6' 6"
• Displacement: 0 lb
• Fuel Tank: 9898 gallon
• Fresh Water: 1619 gallon
• Holding: 1360 gallon
• Cabins: 5
• Heads: 6

Length Overall: 130 ft / 39.6 m
Beam: 26' 3" ft / 8 m
Draft: 6' 6" ft / 1.98 m
Year Completed: 2003
Model Year: 2003
Refit: 2020
Type: Motor Yacht
Tonnage: 280 GT
Displacement: Semi Displacement
Guests: 10
Crew: 7

• Builder: Westport


• Naval Architect: William Garden


• Interior Design/Stylist: Pacific Custom Interiors


• Hull Material: GRP

• Maximum: 24 Knots


• Cruising: 13 Knots


• Range: 24 knots max. 2,500nm range @13kts/52gph/9,984 gallons


• Fuel: 9898.53 Gal / 37470 L


• Water: 1619.37 Gal / 6130 L


• Grey Water: 940 Gal / 3,560 L


• Black Water: 1,360 Gal / 5,150 L


• Lube Oil Capacity: 77 Gal / 291 L

• Engine Type: 2 x MTU 12V 4000


• Horsepower: 2,734 Hp


• Engine Hours: 3,400 hours since W-6 major overhaul


• Engine Serial Numbers:Port,Starboard


• Generators: 2 x Kohler 65EOZD (@1,800 rpm)


• Port Generator Hours: 1,900 hours since overhaul


• Starboard Generator Hours: 1,900 hours since overhaul


• Shore power: ASEA 170‐520V, 3‐Phase, 60Hz


• Batteries: 3 x 12V sets, 6 x 24V sets


• Stabilizer: Naiad 521 with datum control for at‐anchor stabilization


• Stabilizer at Anchor: Yes


• Steering System: Jastram PTO pumps from main engines


• Water Makers: Sea Recovery SRV 1500‐2 AWM


• Bow Thruster: Wesmar Vortex V 2‐16


• Fuel Separator and Filtration: RCI Technologies water separator


• Fresh Water System: Aquabox pump 110V


• Air Conditioning: Dometic 6 ton with 72 BTU

Pilothouse

• SAT COM: Fleet 33 Inmarsat


• Telephone System: Nortel 4 line


• VHF: Icom IC‐M602


• Navtex: Navtex Furuno NX700

Navigation Systems

• Radar: Furuno 2115B X‐band, Furuno 2115 ARPA X‐band


• Gyrocompass: Sperry Marine Navigat X MK2


• Auto Pilot: Sperry Marine Naviplot 4000+


• Depth Sounder: Furuno RD‐33


• GPS: Furuno GP‐33, Bridge Dash

Entertainment Systems

• VSAT1: Yes


• iPads: Yes

Main Galley Equipment

• Oven: 2 x Miele ovens


• Microwave: LG microwave


• Refrigerator: Kitchen Aid refrigerator


• Freezer: Kitchen Aid freezer

Crew Galley/Mess

• Fridge: Whirlpool refrigerator, Uline refrigerator


• Microwave: LG Microwave

Laundry

• Washing Machines: 2 x Miele Washing Machines


• Dryers: 2 x Miele clothes dryers

• Anchor Windlass: Maxwell VWC 6000


• Aft Warping Capstans:


• Anchors: 2 x Poole 600lb


• Anchor Chain: 2 x 400' 5/8"


• Main Tender Davits: Nautical Structures CC2000 EX156 with 909kg capacity


• Passarelle: Bensenzoni

• CCTV System: Pelco CCTV


• Cameras: 9 x cameras


• Monitors: 4 x monitors


• Fire Control System: Custom Westport manufactured system


• Fire Extinguishers: 26 x portable fire extinguishers


• Alarms: Yes


• Life Rafts: 2 x Zodiac Solas 25 life rafts


• Life Rings: 4 x Life rings


• EPIRBS: 2 x EPIRBS


• Flares: 3 x Flares


• Medical Equipment: Medical bag

• Full exterior paint (2017)


• MegaFend- mooring fender system- refurbished/renewed all fender hooks. Added additional fender hooks, for use on the stern


• MegaFend- fenders- purchased various new fenders, for the yacht


• New Furuno System - GPS Gyro


• Added a Master closet divider, for charter purposes


• Repainted boat deck non-skid


• New tender purchase - 16’ Walker Bay w/Honda motor (May 2025)


• Installed all-new exhaust system, for main engines and generators (May 2025)


• Remove and serviced hydraulic system- heat exchangers (3) (August 2025)


• Complete valve-job performed on both MTU- main engines (Mendol) (June 2025)


• Performed complete injector replacement on MTU- mains (2025)


• Installed new dishwasher, in stew pantry (galley)
